Description
This powerful and high-performance vertical machining center is designed for a wide range of applications. It combines speed, power, flexibility, and accuracy—setting a new standard in machining performance.
Featuring a high-rigidity, high-speed spindle and a wide door opening, it allows easy loading and unloading of fixtures and components, enhancing operational efficiency. Built with high-precision roller guideways, ball screws, and a robust, ergonomic structure, the machine ensures excellent accuracy, reliability, and productivity across diverse manufacturing needs
| Category | Specification |
| X / Y / Z Axis Travel | 800 / 510 / 500 mm |
| Distance from Spindle Face to Table Top | 170 – 670 mm |
| Table Size | 1000 x 510 mm |
| Max. Load on Table | 500 kg |
| Table Height from Floor | 925 mm |
| T-Slot Dimensions (n x w x p) | 5 x 18 x 100 mm |
| Tool Shank Type (Std. / Opt.) | BT-40 / HSK A63 |
| Spindle Speed (Std. / Opt.) | 6000 rpm / Up to 12000 rpm |
| Spindle Power (Std. / Opt.) | 15 / 11 kW, 18.5 / 15 kW |
| Cutting Feed | 1 – 10000 mm/min |
| Rapid Traverse (X / Y / Z) | 40 / 40 / 30 m/min |
| Number of Tools (Std. / Opt.) | 24 / 30 / 40 |
| Max. Tool Diameter | 75 / 145 mm |
| Max. Tool Weight | 8 kg |
| Max. Tool Length | 250 mm |
| Tool Change System | Twin Arm |
| Pull Stud Type | MAS – 403 |
| Positioning Accuracy (ISO 230-2) | 0.010 mm |
| Repeatability (ISO 230-2) | ±0.003 mm |
| Control System | FANUC 0iMF+ / SIEMENS 828D / MITSUBISHI M80 |
| Machine Weight (Net) | 6000 kgf |
| Machine Dimensions (W x D x H) | 2200 x 3200 x 2650 mm |
