Description
JG 50 Milling – JG Series is a compact and high-performance CNC milling machine designed for precision machining of small to medium-sized components. Ideal for high-speed milling operations, it ensures accuracy, rigidity, and efficiency for various industrial applications.
| Category | Specification |
| X-Axis Stroke | 500 mm |
| Y-Axis Stroke | 400 mm |
| Z-Axis Stroke | 400 mm |
| Table Size | 600 x 400 mm |
| No. of T-Slots x Pitch | 3 x 14 x 125 mm |
| Maximum Load on Table | 400 kg |
| Spindle Bore Taper | HSK A50 |
| Spindle Speed | 16000 rpm |
| Spindle Motor Power (Low Winding, S1/S6 10%) | 7.5 / 11 kW |
| Spindle Motor Power (High Winding, S1/S2 10 min) | 11 / 18.5 kW |
| Max. Spindle Torque (Low Winding, S1/S6 10%) | 31.1 / 80.8 Nm |
| Max. Spindle Torque (High Winding, S1/S2 10 min) | 17.5 / 29.4 Nm |
| Rapid Traverse (X / Y / Z) | 48 / 48 / 48 m/min (60 / 60 / 60 Optional) |
| Cutting Feed Rate | 20 m/min |
| Guideways | LM Guides |
| No. of Tools | 26 |
| Tool Shank | HSK A50 |
| Max. Tool Diameter (With Adjacent Tool) | 80 mm |
| Max. Tool Length | 320 mm |
| Max. Tool Weight | 3.5 kg |
| Tool Change Time (Tool-to-Tool) | 1 sec |
| Coolant Tank Capacity | 400 litres |
| Dimensions (L x B x H) | 1300 x 4500 x 2900 mm |
| Machine Weight | 6000 kg |
| Controller | Fanuc |
| Positioning Accuracy | ±0.008 mm |
| Repe |
