Description
The MCV-450 is a highly popular, high-performance vertical machining center designed for a wide range of applications. Equipped with a rigid, high-speed spindle, it delivers an ideal balance of speed, power, flexibility, and accuracy, setting a new benchmark in machining performance.
Its wide door opening facilitates easy loading and unloading of fixtures and components, improving operational efficiency. Built with high-precision roller guideways, ball screws, and a robust structure combined with an ergonomic design, the machine ensures exceptional accuracy and productivity.
To further enhance versatility and performance, the MCV-450 can be configured with linear or rotary pallet changers, 4th and 5th axis rotary tables, production systems, and full automation solutions tailored to meet diverse manufacturing needs.
| Category | Specification |
| Travels (X / Y / Z Axis) | 800 / 450 / 500 mm |
| Distance from Spindle Face to Table Top | 175 – 675 mm |
| Table Size | 1000 x 450 mm |
| Max. Load on Table (Std. / Opt.) | 400 / 700 kg |
| Table Height from Floor | 925 mm |
| Tool Shank Type | BT-40 |
| Spindle Speed (Std. / Opt.) | 6000 (Up to 10000) rpm |
| Spindle Power (Std. / Opt.) | 11 / 7.5 (15 / 11) kW |
| Cutting Feed | 1 – 10000 mm/min |
| Rapid Traverse | 36 / 36 / 36 m/min |
| Number of Tools | 24 |
| Tool Diameter Max. / Adjacent Tool Empty | 80 / 155 mm |
| Tool Weight Max. | 8 kg |
| Tool Length Max. | 250 mm |
| Tool Change System | Twin Arm |
| Positioning Accuracy (ISO 230-2) | 0.010 mm |
| Repeatability | ±0.003 mm |
| Machine Width x Depth x Height | 2.2 x 3.1 x 2.55 m |
| Machine Weight – Net | 5300 kg |
| Control System | Fanuc 0iMF+ |
