Description
The SMART Ultra Turning Center is a high-speed CNC lathe designed for precision turning of complex components with enhanced productivity. Its advanced features make it ideal for mass production in the automotive, aerospace, and general engineering industries.
| Category | Specification |
| Swing Over Bed | 460 mm |
| Maximum Chuck Diameter | 200 / 169 mm |
| Maximum Turning Diameter | 290 mm |
| Maximum Turning Length | 370 / 325 mm |
| Admit Between Centres | 434 mm |
| Spindle Nose Type | Flat (Ø140 mm) |
| Hole Through Spindle | 53 mm |
| Spindle Speed | 4000 rpm |
| Spindle Motor Power | Siemens: 5.5 / 8.3 kW Fanuc: 5.5 / 7.5 kW Mitsubishi: 5.5 / 7.5 kW |
| Inclination of Carriage | 30° to Horizontal Plane |
| X-Axis Travel | 155 mm |
| Z-Axis Travel | 420 mm |
| Rapid Traverse (X / Z) Axes | 30 / 30 m/min |
| Number of Stations | 8 |
| Tool Shank Size | 25 x 25 mm |
| Maximum Boring Bar Diameter | 40 mm |
| Turret Indexing Type | Hydraulic |
| Turret Indexing Time | < 1.0 sec |
| Quill Diameter | 65 mm |
| Quill Stroke | 80 mm |
| Quill Taper | MT-4 |
| Controller Type | Fanuc / Siemens / Mitsubishi |
| Dimensions (L x W x H) | 2295 x 1410 x 1860 mm |
| Machine Weight | 2300 kg |
