Description
This compact and economical vertical drill tap machining center features increased stroke lengths and rapid traverse rates compared to standard models. It is well-suited for high-precision aluminum and cast iron applications. The machine supports a maximum table load of 200 kgf and comes equipped with a table size of 650 mm x 310 mm. It offers stroke dimensions of 400 mm (X-axis), 300 mm (Y-axis), and 250 mm (Z-axis), making it a reliable and efficient solution for demanding machining tasks.
| Item | Spec |
| Table Size | 500×270 mm |
| Max. Table Load | 150 kg |
| Table Height | 840 mm |
| T-Slot | 3×14×80 mm |
| Tool Shank | BT-30 |
| Spindle Speed | 60–6000 / 80–8000 rpm |
| Spindle Power | 5.5 / 3.7 kW |
| Cutting Feed | 1–10000 mm/min |
| Rapid Traverse (X/Y/Z) | 25/25/18 m/min |
| ATC Tools | 8 |
| Tool Ø / Weight Max. | 80 mm / 2.5 kg |
| Tool Length Max. | 200 mm |
| Tool Changer | Twin Arm |
| Pull Stud | MAS-403 |
| Accuracy / Repeat. | 0.010 mm / ±0.003 mm |
| Control System | FANUC 0iMF+ |
| Machine Weight | 1800 kgf |
| Floor Space | 1350×1900 mm |
