Description
This compact and rigid machining center is ideal for machining aluminum, cast iron, and steel components. It comes equipped with a BT-40 spindle and a 24-tool side-mounted automatic tool changer. With its robust structure and high-precision components, the machine ensures excellent accuracy, reliability, and productivity in demanding applications.
| Category | Specification |
| Table | |
| Table Size | 800 × 400 mm |
| T-Slot (N × W × P) | 4 × 14 × 100 mm |
| Max. Load on Table | 400 kgf |
| Machine Capacity | |
| Travels (X / Y / Z) | 500 / 400 / 500 mm |
| Spindle Face to Table | 195 – 695 mm |
| Spindle | |
| Spindle Nose Taper | 7 / 24 No. 40 |
| Spindle Speed (Std. / Opt.) | 6000 rpm / up to 12000 rpm |
| Rapid Traverse (X / Y / Z) | 40 / 40 / 40 m/min |
| Spindle Power | |
| FANUC (0iMF+) | 7.5 / 5.5 kW (Opt. 11 / 7.5 kW) |
| Mitsubishi (M80) | 7.5 / 5.5 kW (Opt. 11 / 7.5 kW) |
| Siemens (828D) | 7.5 / 5.5 kW (Opt. 7 / 10.5 kW) |
| Automatic Tool Changer | |
| Number of Tools | 24 / 30 |
| Tool Change System | Twin Arm |
| Tool Shank Type | BT-40 |
| Optional Pallet Changer | |
| Linear Type Pallet Size | 600 × 385 mm (2 Pallets) |
| Rotary Type Pallet Size | 600 × 400 mm (2 Pallets) |
| Installation Data | |
| Machine Dimensions (W × D) | 1.9 × 3.0 m |
| Net Machine Weight | 4700 kgf |
