NewCNC Turning Centre
DXG Series Automated CNC Turning Centre
Automation Turning Center for Small Disc Components
- Configured to order – control, spindle and options to suit your part
- Lead time and price confirmed in writing with your quote
- Installation, commissioning and operator training available
Specifications
| Capacity | DXG 100 | DXG 100i SP | DXG 200 | |
| Swing Over Bed | mm | 470 | 470 | 500 |
| Std. Turning Dia. | mm | 100 | 100 | 250 |
| Max. Job Swing Dia.* | mm | 200 | 200 | 365 |
| Max. Turning Length * | mm | 200 | 200 | 500 |
| Slides | ||||
| X-Axis Travel (Cross) | mm | 360 | 360 | 200 |
| Z-Axis Travel (Longitudinal) | mm | 200 | 200 | 500 |
| Rapid Feed (X & Z Axis) | m/min | 24 | 24 | 24 |
| Main Spindle | ||||
| Spindle Motor Power -Fanuc | kW | 11/7.5 | 11/7.5 | 11/9 |
| Spindle Motor Power -Siemens | kW | 9.8/7.5 | 9.8/7.5 | 13.5/9 (14.4/11) |
| Spindle Bore | mm | 55 | 55 | 70 (90) |
| Spindle Nose | A2-5 | A2-5 | A26 (A2-8) | |
| Max. Bar Capacity | mm | 44 | 44 | 52 (75) |
| Spindle Speed Range | rpm | 50-4000 | 50-4000 | 50-4000 (3500) |
| Tooling (Gang Type) | ||||
| Max. Boring Bar Capacity | mm | 40 | 40 | 40 |
| Tool Size (Cross Sectional) | mm | 25 x 25 | 25 x 25 | 25 x 25 |
| Automated Gantry Robot Loader/Unloader | ||||
| Work piece Dimension (Loader Capacity) | mm | Ø100 x 45 | Ø 105 x 45 | Ø 210 x 100 |
| Max. Part Weight (One Side) | kg | 2.5 | 2.5 | 6 |
| Loader X (Left/Right) Axis Stroke | mm | 1500 | – | – |
| Max. Speed (X Axis) | m/min | 120 | – | 90 |
| Loader Y (Up/Down) Axis Stroke | mm | 560 | – | – |
| Max. Speed (Y Axis) | m/min | 110 | – | 90 |
| Loader Z (Left/Right) Axis Stroke | mm | – | 250 | – |
| Max. Speed (Z Axis) | m/min | – | 50 | – |
| Loader X (Up/Down) Axis Stroke | mm | – | 375 | – |
| Max. Speed (X Axis) | m/min | – | 110 | – |
| Jaw Stroke Per Jaw (Loader Chuck) | mm/deg. | 4 | 6 | 10 |
| Rotation (Swivel Unit) | deg | 90 | – | 90° |
| Tail Stock | ||||
| Quill Dia. | mm | – | – | 85 |
| Quill Stroke | mm | – | – | 120 |
| Thrust | kgf | – | – | 500 |
| Accuracy (As per VDI/DGQ 3441) | ||||
| Positioning Uncertainty (P) | mm | 0.007 | 0.007 | 0.007 |
| Repeatability (Ps medium) | mm | 0.005 | 0.005 | 0.005 |
| Other Data | ||||
| Machine Weight #(Approx.) | Kg | 2900 | 2300 | 4800 |
| Machine Dimension # (Approx.) | ||||
| Length | mm | 2960 | 3150 | 3700 |
| Width | mm | 1400 | 3000 | 2200 |
| Height | mm | 3080 | 2500 | 3250 |
About this machine
Automation Turning Center for Small Disc Components
Designed to meet the demands of mass production, this automated turning solution is ideal for small disc-type components requiring consistent precision and unmanned operation. Its rigid mono-block structure ensures stability and high dynamic performance during continuous use.
Featuring an integrated 2-axis gantry system and automatic feeder, it allows seamless job handling without manual intervention. Perfect for multi-process integration, this system enhances productivity and efficiency in large-scale manufacturing environments.
Is a cnc turning centre right for your part?
2-axis CNC lathes, slant-bed turning centres and chuckers for shafts, flanges, bushes and other round parts.
Choose the chuck to grip your largest diameter, the turning length for your longest part, and bar capacity if you feed bar. Add a tailstock or steady rest for long shafts.
Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.
Questions buyers ask
What is the lead time for this machine?
New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.
Which chuck size do I need on a CNC lathe?
One that grips your largest diameter securely. Most small and medium parts run on 165–250 mm chucks; flanges and larger discs need 300 mm or more.
What is a chucker?
A compact CNC lathe built for short, disc-type parts held in a chuck – bearing races, gear blanks, flanges – often with a loader for unmanned runs.
Should I choose a flat-bed or slant-bed lathe?
Slant-bed turning centres clear chips better, are more rigid and suit production. Flat-bed CNC lathes are simpler and cheaper for general work and large diameters.
Is installation and training included?
Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
