SHA-12 Sliding Head Automat
NewSliding Head Automat

SHA-12 Sliding Head Automat

This high-precision CNC turning center is specifically designed for high productivity in machining small-sized components.

  • Spindle12000 rpm
Get price & availability WhatsApp Call
  • Configured to order – control, spindle and options to suit your part
  • Lead time and price confirmed in writing with your quote
  • Installation, commissioning and operator training available

Specifications

CategorySpecification
Maximum Machining Diameter12 mm
Maximum Machining Length80 mm
Spindle Thru Hole Diameter16 mm
Max. Main Spindle Speed12000 rpm
Max. Sub-Spindle Speed12000 rpm
Max. Spindle Speed of Gang Rotary Tool6000 rpm
X1-Axis Rapid Traverse24 m/min
Y1-Axis Rapid Traverse24 m/min
X2, Z1, Z2-Axis Rapid Traverse32 m/min
Main and Sub-Spindle Power1.5 / 2.2 kW
Spindle Motor Power1.5 / 2.2 kW
Maximum Number of Tools20
Overall Dimensions (L x W x H)1242 x 1916 x 1916 mm
Weight (Without Packing)~1950 kg

About this machine

This high-precision CNC turning center is specifically designed for high productivity in machining small-sized components. Offered in a 5-axis configuration, it features a powerful built-in motor driving the main spindle with speeds up to 12,000 rpm.
The machine accommodates up to 20 tools, including 3 rotary tools, and is compatible with a bar feeder for continuous operation with bar diameters ranging from 3 mm to 12 mm. Its advanced capabilities make it ideal for precision machining in high-volume production environments.

Specifications are as provided by the manufacturer or seller. Please confirm the exact configuration with your quote.

Is a sliding head automat right for your part?

Swiss-type sliding head lathes and multi-spindle bar automats for long, slender and high-volume small parts.

Sliding head (Swiss-type) machines support the bar in a guide bush close to the tool, so long, slender parts stay accurate. Multi-spindle automats suit very high volumes of simple parts.

Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.

Questions buyers ask

What is the lead time for this machine?

New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.

What parts suit a sliding head automat?

Small, long and slender parts from bar – pins, shafts, connectors, medical and electronic parts – usually up to about 20–32 mm diameter.

Cam automat or CNC sliding head?

Cam automats are economical for very long runs of one part. CNC sliding head machines change over faster and handle more complex parts.

Do sliding head machines need a bar feeder?

Yes, a bar feeder or loader is normally part of the package for continuous production.

Is installation and training included?

Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
