a500Z Horizontal Machining Centre
NewHorizontal Machining Centre

a500Z Horizontal Machining Centre

a500Z – 5-Axis Horizontal Machining Center The a500Z is a powerful 5-axis horizontal machining center designed for high-speed, high-precision multi-face machining in a single setup.

Get price & availability WhatsApp Call
  • Configured to order – control, spindle and options to suit your part
  • Lead time and price confirmed in writing with your quote
  • Installation, commissioning and operator training available

Specifications

ParameterSpecification
Pallet Size19.7”
Travel (X / Y / Z)X: 28.7″ Y: 29.5″ Z: 19.7″ – 27.6″
B-Axis360° (Unlimited) – Direct Drive
C-Axis180° – Direct Drive
Spindle RPM14,000 (std.) / 20,000 (optional)
Rapid Traverse Rate2,362 ipm
Cutting Feedrate1,968 ipm
Maximum Workpiece SizeØ24.9” × 19.7” High
Maximum Payload880 lbs
ATC Capacity60 tools (std.) / 133, 218, 313 tools (optional)
Tool Change Time (Tool to Tool)0.9 sec
Max. Tool Diameter6.7”
Max. Tool Weight26.4 lbs

About this machine

a500Z – 5-Axis Horizontal Machining Center
The a500Z is a powerful 5-axis horizontal machining center designed for high-speed, high-precision multi-face machining in a single setup. With a compact footprint, tilting rotary table, and rigid construction, it delivers outstanding performance in aerospace, medical, and precision engineering sectors. Its advanced design ensures superior part quality, minimal setup time, and maximum productivity.

Specifications are as provided by the manufacturer or seller. Please confirm the exact configuration with your quote.

Is a horizontal machining centre right for your part?

HMCs with indexing tables and pallet changers, and horizontal boring machines for multi-face and heavy work.

HMCs machine several faces in one setup with an indexing table, clear chips well and – with a pallet changer – load the next part while the current one is cut. Horizontal boring machines handle large, heavy work.

Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.

Questions buyers ask

What is the lead time for this machine?

New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.

Why choose an HMC over a VMC?

For multi-face parts and high volumes: an HMC reaches four sides in one setup, chips fall away from the work, and pallet changers keep the spindle busy.

What is an automatic pallet changer (APC)?

Two or more pallets that swap automatically, so the operator loads the next part while the machine cuts the current one.

Box guideways or linear guideways?

Box guideways damp vibration and suit heavy cutting; linear guideways give faster rapids and lower friction for high-speed production.

Is installation and training included?

Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
