LCXT-20 Turn-Mill Centre
NewTurn-Mill Centre

LCXT-20 Turn-Mill Centre

This twin-spindle, twin-turret CNC turning center is designed for high productivity while maintaining a compact footprint of 4840 mm x 2350 mm.

  • Turning Ø360 mm
  • Turn length190 mm
  • Spindle3500 rpm
  • Chuck250 mm
  • Travel190 mm
Get price & availability WhatsApp Call
  • Configured to order – control, spindle and options to suit your part
  • Lead time and price confirmed in writing with your quote
  • Installation, commissioning and operator training available

Specifications

CategorySpecification
Swing Over Bed458 mm
Swing Over Carriage458 mm
Maximum Turning Diameter360 mm
Maximum Turning Length190 mm
Spindle Size / NoseA2-6
Bore Through Spindle63 mm
Max. Spindle Speed3500 rpm
Spindle Motor Power (Fanuc, Continuous)11 kW
Spindle Motor Power (Fanuc, 30 min)15 kW
Full Power Range (FANUC)875 – 3500 rpm
Standard Chuck Size250 mm
X-Axis Stroke190 mm
X-Axis Rapid Traverse24 m/min
X-Axis GuidewaysLM Guideways
Z-Axis Stroke190 mm
Z-Axis Rapid Traverse24 m/min
Z-Axis GuidewaysRam Type Hardened Guide
Turret TypeServo
Number of Stations10
Max. Boring Bar Diameter40 mm
OD Turning Tool Size25 x 25 mm
Coolant Tank Capacity300 litres
Hydraulic Pump Capacity14 lpm
Hydraulic Power Pack Tank Capacity45 litres
Dimensions (L x W x H)2390 x 2220 x 2171 mm
Overall Weight (Without Packing)~4400 kg

About this machine

This twin-spindle, twin-turret CNC turning center is designed for high productivity while maintaining a compact footprint of 4840 mm x 2350 mm. With both first and second operations performed on a single machine, it minimizes floor space requirements and improves workflow efficiency.

The machine features a split-bed design and modular construction, enabling seamless integration with additional units. It is automation-ready and supports both gantry and robotic systems, making it ideal for high-volume, automated manufacturing setups.

Specifications are as provided by the manufacturer or seller. Please confirm the exact configuration with your quote.

Is a turn-mill centre right for your part?

Lathes with live tools, C/Y axis, sub-spindles or twin turrets that turn, mill, drill and tap a part in one setup.

Pick a turn-mill centre when parts need flats, cross holes, keyways or off-centre features. A Y axis machines away from the centreline; a sub-spindle finishes the back side in the same cycle.

Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.

Questions buyers ask

What is the lead time for this machine?

New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.

What does a Y axis add to a turning centre?

It lets live tools move off the part centreline, so you can mill flats, pockets and off-centre holes without a second machine.

What is a twin-spindle lathe?

A lathe with two spindles – and often two turrets – that machines both ends of a part in one cycle, raising output per square metre of floor.

Is a turn-mill centre worth it?

When parts currently need a lathe plus a VMC, one turn-mill setup removes handling, waiting and a second fixture, and improves accuracy between features.

Is installation and training included?

Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
