LT-2 LM 500 MY Turn-Mill Centre
NewTurn-Mill Centre

LT-2 LM 500 MY Turn-Mill Centre

This horizontal turn-mill center with Y-axis capability is designed for advanced multi-tasking operations.

  • Turning Ø386 mm
  • Bar Ø51 mm
  • Spindle4000 rpm
  • Travel198 mm
Get price & availability WhatsApp Call
  • Configured to order – control, spindle and options to suit your part
  • Lead time and price confirmed in writing with your quote
  • Installation, commissioning and operator training available

Specifications

CategorySpecification
Swing Over Bed610 mm
Swing Over Carriage386 mm
Maximum Turning Diameter386 mm
Maximum Turning LengthRefer machining range diagram
Distance Between CentresRefer machining range diagram
Spindle Size / NoseA2-6
Max. Bar Capacity51 mm
Bore Through Spindle63 mm
Max. Spindle Speed4000 rpm
Spindle Motor Power (Fanuc, Continuous)9 kW
Spindle Motor Power (Fanuc, 30 min)11 kW
Spindle Motor Power (Siemens, Continuous)9 kW
Spindle Motor Power (Siemens, S6-40%)11 kW
Full Power Range (FANUC)500 – 4000 rpm
Full Power Range (Siemens)NA
Standard Chuck SizeNA
Sub-Spindle Size / Nose—
Bore Through Sub-SpindleNA
Max. Sub-Spindle SpeedNA
Sub-Spindle Motor Power (30 min)NA
Sub-Spindle Motor Power (Continuous)NA
Full Power Range (FANUC, Sub-Spindle)NA
Full Power Range (Siemens, Sub-Spindle)NA
X-Axis Stroke198 mm
X-Axis Rapid Traverse20 m/min
X-Axis GuidewaysLM Guideways
Z-Axis Stroke540 mm
Z-Axis Rapid Traverse20 m/min
Z-Axis GuidewaysLM Guideways
Y-Axis Stroke±40 mm
Y-Axis Rapid Traverse20 m/min
Y-Axis GuidewaysLM Guideways
Turret TypeRotary Tool Turret (R)
Rotary Tool Motor Power4.5 kW
Number of Stations12
Max. Boring Bar DiameterØ32 mm
OD Turning Tool Size20 x 20 mm
Tailstock Base TravelNA
Tailstock Quill DiameterNA
Tailstock Quill TravelNA
Tailstock Quill TaperNA
Coolant Tank Capacity120 litres
Hydraulic Pump Capacity14 lpm
Hydraulic Power Pack Tank Capacity45 litres
Dimensions (L x W x H)3200 x 1900 x 1950 mm
Overall Weight (Without Packing)~4800 kg

About this machine

This horizontal turn-mill center with Y-axis capability is designed for advanced multi-tasking operations. It supports both C-axis and Y-axes functions, allowing for complex machining processes such as milling, drilling, tapping, and front/back-end turning—all in a single setup.

The machine features an A2-6 spindle configuration and handles components with a maximum turning diameter of 386 mm and a turning length of up to 500 mm. Built with linear motion guideways, it is equipped with a 12-station rotary tool turret (VDI30 radial disc), ensuring precise and efficient tool handling for diverse machining applications.

Specifications are as provided by the manufacturer or seller. Please confirm the exact configuration with your quote.

Is a turn-mill centre right for your part?

Lathes with live tools, C/Y axis, sub-spindles or twin turrets that turn, mill, drill and tap a part in one setup.

Pick a turn-mill centre when parts need flats, cross holes, keyways or off-centre features. A Y axis machines away from the centreline; a sub-spindle finishes the back side in the same cycle.

Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.

Questions buyers ask

What is the lead time for this machine?

New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.

What does a Y axis add to a turning centre?

It lets live tools move off the part centreline, so you can mill flats, pockets and off-centre holes without a second machine.

What is a twin-spindle lathe?

A lathe with two spindles – and often two turrets – that machines both ends of a part in one cycle, raising output per square metre of floor.

Is a turn-mill centre worth it?

When parts currently need a lathe plus a VMC, one turn-mill setup removes handling, waiting and a second fixture, and improves accuracy between features.

Is installation and training included?

Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
