Mill Tap Series Drill-Tap Machining Centre
NewDrill-Tap Machining Centre

Mill Tap Series Drill-Tap Machining Centre

Mill Tap Series – Drilling and Tapping Centers

  • Table660 x 360 mm
  • Travel510 / 410 / 510 mm
  • Spindle8000 rpm
Get price & availability WhatsApp Call
  • Configured to order – control, spindle and options to suit your part
  • Lead time and price confirmed in writing with your quote
  • Installation, commissioning and operator training available

Specifications

CategorySpecification
Table Size660 x 360 mm
T-Slot Dimension3 x 14 x 125 mm
Distance from Floor to Table1020 mm
Max. Load on Table400 kgf
X / Y / Z Axis Travel510 / 410 / 510 mm
Spindle Face to Table Top100 – 610 mm
Rapid Traverse (X/Y/Z)40 / 40 / 32 m/min
Cutting Feed10 m/min
Spindle Speed Range8000 rpm
Spindle Motor (Fanuc)5.5 / 3.7 kW
Spindle Motor (Siemens)5.6 / 3.7 kW
Front Bearing Bore50 mm
Spindle NoseBT 30
Number of Tools20
Max. Tool Dia. (All/Adj.)63 / 80 mm
Max. Tool Weight3 kg
Max. Tool Length200 mm
Positioning Accuracy (P)0.01 mm
Repeatability (Ps Medium)0.005 mm
Weight (Approx.)3350 kg
Dimensions (L x W x H)3265 x 2380 x 2685 mm

About this machine

Mill Tap Series – Drilling and Tapping Centers

The Mill Tap Series is engineered for industries demanding high-speed drilling and tapping performance with superior productivity. Built with a rigid C-frame, fixed column, and FEM-validated ribbed structure, it ensures stability and durability during high-speed machining.

This 3-axis machining center offers rapid tool changes with a twin-arm automatic tool changer and efficient chip evacuation to minimize non-cutting time. It’s well-suited for complex 3-axis and 4-axis applications across a wide range of manufacturing sectors.

Specifications are as provided by the manufacturer or seller. Please confirm the exact configuration with your quote.

Is a drill-tap machining centre right for your part?

Compact BT-30 machining centres built for fast drilling, tapping and light milling of aluminium and cast-iron parts.

Drill-tap centres use a light BT-30 spindle, fast tool change and high rapids to cut cycle times on aluminium and cast-iron parts with many holes and threads.

Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.

Questions buyers ask

What is the lead time for this machine?

New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.

Drill-tap centre or VMC?

Choose a drill-tap centre when most of the cycle is drilling, tapping and light milling on small parts. Choose a BT-40 VMC for heavier milling and steel.

Can a drill-tap centre machine steel?

Yes, for light cuts, drilling and tapping. Heavy roughing in steel is better on a BT-40 or BT-50 machine.

What is BBT-30?

A dual-contact version of the BT-30 holder that touches the spindle face as well as the taper, improving rigidity and accuracy at high speed.

Is installation and training included?

Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
