NewGantry Machining Centre
Column-Moving High-Speed Gantry Machining Centre
Column Moving High Speed Gantry Machining is a specialized CNC machining technology designed for processing large and heavy components with high precision.
- Travel3000 mm
- Table2000 × 3000 mm
- Spindle10 – 24000 rpm
- Configured to order – control, spindle and options to suit your part
- Lead time and price confirmed in writing with your quote
- Installation, commissioning and operator training available
Specifications
| Category | Unit | Specification |
|---|---|---|
| Model | HGM2030 / HGM2030AC | |
| Processing Range | ||
| Gantry Effective Width | mm | 2050 |
| X Travel | mm | 3000 |
| Y Travel | mm | 2000 |
| Z Travel | mm | 700 |
| Distance: Spindle End Face to Table | mm | 50 – 750 |
| Distance: Horizontal Spindle Center to Table | mm | 312 – 1012 |
| Table | ||
| Table Size (W × L) | mm | 2000 × 3000 |
| Max Loading | T | 6T |
| Column Width | mm | 2050 |
| Table T-slot | r/min | 12 – 18 × 250 |
| A/C Head | ||
| C Axis Rotation Range | ° | ±180° |
| A Axis Rotation Range | ° | ±90° |
| Vertical Head Spindle Speed Range | rpm | 10 – 24000 |
| Spindle Torque | N·m | 19 / 21 |
| Spindle Taper | HSK-A63 | |
| Feed | ||
| Cutting Feed Speed Range | m/min | 10 – 20 |
| X Axis Rapid Speed | m/min | 30 |
| Y Axis Rapid Speed | m/min | 40 |
| Z Axis Rapid Speed | m/min | 36 |
| Accuracy (Semi-closed Loop) | ||
| X-axis Positioning Accuracy | mm | 0.045 |
| Y-axis Positioning Accuracy | mm | 0.035 |
| Z-axis Positioning Accuracy | mm | 0.025 |
| X-axis Repeatability | mm | 0.025 |
| Y-axis Repeatability | mm | 0.020 |
| Z-axis Repeatability | mm | 0.015 |
| Control System | SIEMENS | |
| Others | ||
| Machine Size (L × W × H) | mm | 7000 × 4600 × 4000 |
| Machine Weight | T | 25T |
About this machine
Column Moving High Speed Gantry Machining is a specialized CNC machining technology designed for processing large and heavy components with high precision. In this system, the column moves instead of the table, providing excellent stability and load-bearing capacity. This design reduces vibration, saves floor space, and ensures consistent accuracy during high-speed operations. Widely used in aerospace, automotive, and mold-making industries, it delivers efficient and reliable performance for complex and demanding machining tasks.
Is a gantry machining centre right for your part?
Double-column, bridge and moving-beam machines for large plates, frames, dies and long components.
Gantry, bridge and moving-beam machines carry the spindle over the work, so very large, heavy plates, frames and dies can be machined without a huge table travel.
Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.
Questions buyers ask
What is the lead time for this machine?
New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.
What is a gantry machining centre used for?
Large plates, machine beds, frames, press tools, moulds and long components that will not fit on a VMC.
Moving column or moving table?
With a moving column or beam, the heavy part stays still – better for very large and heavy work and a smaller footprint for the length machined.
Do gantry machines need a special foundation?
Usually yes. We share the layout and foundation details with the quote so civil work can be planned early.
Is installation and training included?
Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
