- JV 150 Vertical Machining Centre
NewVertical Machining Centre
JV 150 Vertical Machining Centre
The JV 150 is a high-performance vertical machining center designed for precision machining of large components.
- Travel1550 x 760 x 760 mm
- Table1700 x 700 mm
- Spindle6000 rpm
- ControlMitsubishi
- Configured to order – control, spindle and options to suit your part
- Lead time and price confirmed in writing with your quote
- Installation, commissioning and operator training available
Specifications
| Category | Specification |
| X / Y / Z Axis Travel | 1550 x 760 x 760 mm |
| Table Size | 1700 x 700 mm |
| Max. Weight on Table | 1300 kg |
| Max. Spindle Speed | 6000 rpm |
| Spindle Bore Taper | BT 50 |
| Motor Power (Cont. / Int.) | 18.5 / 22 kW |
| Max. Spindle Torque (Cont. / Int.) | 307 / 525 Nm |
| Rapid Traverse Rate (X / Y / Z) | 24 / 30 / 24 m/min |
| Guideways | LM Roller |
| Number of Tools | 24 |
| Max. Tool Length | 400 mm |
| Tool Change Time (Tool to Tool) | 4.4 sec |
| Floor Space | 12.8 m² |
| Controller | Mitsubishi |
About this machine
The JV 150 is a high-performance vertical machining center designed for precision machining of large components. It offers a generous working envelope, robust spindle capabilities, and advanced automation options, making it suitable for industries such as automotive, aerospace, and general engineering.
Is a vertical machining centre right for your part?
3-, 4- and 5-axis VMCs for prismatic parts, dies, moulds, housings and brackets.
Size a VMC from your largest part plus fixture (X/Y/Z travel and table), choose BT-40 for general work, BT-50 for heavy cuts or HSK and high rpm for finishing, and count the tools in your longest program.
Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.
Questions buyers ask
What is the lead time for this machine?
New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.
What size VMC do I need?
Your largest part plus fixture and tool clearance in X, Y and Z, with table size and load to match. A 20–25% margin covers most future work.
Which control is best on a VMC?
Fanuc, Siemens and Mitsubishi are all proven. Choose the one your programmers and service partners know best.
Do I need a 4th axis?
If you machine several faces or hole patterns around a part, a 4th-axis rotary table saves setups. True 5-axis is needed for blades, impellers and complex moulds.
Is installation and training included?
Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
