- PS105 Vertical Machining Centre
NewVertical Machining Centre
PS105 Vertical Machining Centre
PS105 Vertical Machining Center – Power, Precision, and Performance The PS105 is a high-performance vertical machining center designed for precision machining in industries like aerospace, medical, and automotive.
- Table51.1" x 20"
- Spindle14,000 rpm
- TaperCAT40 (HSK-A63 optional)
- Configured to order – control, spindle and options to suit your part
- Lead time and price confirmed in writing with your quote
- Installation, commissioning and operator training available
Specifications
| Parameter | Specification |
| Table Size | 51.1″ x 20″ |
| Travel (X / Y / Z) | X: 41.3″ Y: 20.0″ Z: 18.1″ |
| Spindle Speed (RPM) | 14,000 rpm |
| Spindle Taper | CAT40 (HSK-A63 optional) |
| Rapid Traverse Rate | X: 1,890 ipm Y/Z: 1,417 ipm |
| Cutting Feedrate | 1,181 ipm |
| Maximum Payload | 1,763 lbs |
| ATC Capacity | 30 tools (optional 60 tools) |
| Max. Tool Weight | 17.6 lbs |
| Optional ATC Capacity | Yes |
About this machine
PS105 Vertical Machining Center – Power, Precision, and Performance
The PS105 is a high-performance vertical machining center designed for precision machining in industries like aerospace, medical, and automotive. With its rigid structure, high-speed spindle, and advanced motion control, it delivers excellent surface finishes, tight tolerances, and reduced cycle times—ideal for complex and high-volume production needs.
Is a vertical machining centre right for your part?
3-, 4- and 5-axis VMCs for prismatic parts, dies, moulds, housings and brackets.
Size a VMC from your largest part plus fixture (X/Y/Z travel and table), choose BT-40 for general work, BT-50 for heavy cuts or HSK and high rpm for finishing, and count the tools in your longest program.
Send your part drawing, material and monthly quantity, and we will confirm whether this machine fits – or suggest one that fits better.
Questions buyers ask
What is the lead time for this machine?
New machines are built to order. We confirm the lead time and the exact configuration – control, spindle, tool changer and options – with your quote.
What size VMC do I need?
Your largest part plus fixture and tool clearance in X, Y and Z, with table size and load to match. A 20–25% margin covers most future work.
Which control is best on a VMC?
Fanuc, Siemens and Mitsubishi are all proven. Choose the one your programmers and service partners know best.
Do I need a 4th axis?
If you machine several faces or hole patterns around a part, a 4th-axis rotary table saves setups. True 5-axis is needed for blades, impellers and complex moulds.
Is installation and training included?
Installation, commissioning and operator training are listed in the quote, so you know exactly what is included.
